Incubator
- Construction : Interior is made of SS304 (Matt Finish) & Exterior is made of either SS304 (Matt Finish) or Mild Steel powder coated. Phoenix incubators are insulated with PUF insulation.
- Heating System : Long lasting SS tubular heater.
- Temp. Control : Auto Tune PID Controller with PT 100
- Temp. Range : 5°C above ambient to 60°C
- Temp.Accuracy : +/- 0.2°C
- Temp. Uniformity : +/- 1.0°C
- Alarms : Temperature deviation
- Features : Wire Mesh trays with adjustable racks, Rounds inner corners for cleaning, Space saving design, Forced air circulation for better uniformity throughout the incubator, Inner glass door for observation, Printing Facility(Optional).
- Safety : Thermostat for in case of any electronic malfunction
- Power Supply : 230VAC, 50Hz, Mains.
| Model | Inner Size (LXWXH) mm |
External Size (LXWXH) mm |
Capacity Cu.Ft / Ltrs. |
Trays | Tray Size |
| INS090M4 / S4 | 450 x 450 x 450 | 775 x 610 x 900 | 3.0 / 90 | 2Nos. | 410 x 410 |
| INS100M4 / S4 | 500 x 450 x 450 | 825 x 610 x 950 | 3.5 / 100 | 2Nos. | 460 x 410 |
| INS150M4 / S4 | 500 x 550 x 550 | 825 x 710 x 950 | 5.0 / 150 | 2Nos. | 460 x 510 |
| INS200M4 / S4 | 600 x 600 x 600 | 925 x 760 x 1000 | 7.0 / 200 | 2Nos. | 560 x 560 |
| INS350M4 / S4 | 600 x 600 x 1000 | 1050 x 760 x 1350 | 12.5 / 350 | 3Nos. | 560 x 560 |
Note: M4- Models are standard model Inner SS304 Matt Finish & Exterior M.S. Powder Coated
S4- Models are G.M.P Models Inner SS304 Matt Finish & Exterior SS304 Matt Finish
